Trail Sport starts here
More grip, more suspension, more flow, more responsive but totally planted trail handling. We’ve never built a better bike to start your off-road experience on than the new 603 Sport Hardtail.
120mm suspension fork, dialled bar and stem dimensions are a license to thrill, while twin chainring Shimano gears, fast rolling tyres and an on/off switch on the suspension mean short road sections between the best bits - or daily work duty between wild weekends - aren’t just easy, but enjoyable too. Because the only riders having a hard time should be the ones trying to keep up with you.
SPECIFICATION
Colour- Gloss Cement Burnt Orange/Slate
Frame- 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Internal Cable Routing with BBX, Chainstay Post Mount Dropouts
Fork- SR Suntour XCR-LO 27.5", 120mm Travel, Tapered Steerer, Hydro Lockout, Fixed Rebound Damping, Black Stanchions
Rear Shock- N/A
Headset- FEIMIN H807B, Semi Integrated, 1 1/8" Lower 1 1/2 Lower Caged Bearings
Rear Hub- Alloy, Cup & Cone, Double Seal, 32 Hole
Front Hub- Alloy, Cup & Cone, Double Seal, 32 Hole
Spokes- 2.0mm, PG, Black Stainless, Brass Nipples
Rims- Whyte Trail 25, Tubeless compatible, 32 Hole
Tyre- MAXXIS Forekaster 27.5" x 2.35" Front, MAXXIS Recon Race 27.5" x 2.25" Rear Wire Bead
Shift Levers- Shimano Altus SL-M2010, 9 Speed
Front Mech- Shimano Altus FD-M2020
Rear Mech- Shimano Altus RD-M2000-SGS, 9 Speed
Cassette- Shimano CS-HG-200, 11-36, 9 Speed
Chain- SunRace, 9 Speed
Crankset- Shimano FC-MT101, Double 36-22, 9 Speed
Bottom Bracket- Square Interface, Cartridge Bearings, 73mm
Seatpost- Whyte 6061 Alloy, 12mm Offset, 30.9mm x S/M 350mm, L/XL 400mm, 2 Bolt Clamp
Saddle- Whyte Custom
Handlebar- Whyte 6061 Alloy, 30mm Rise, 31.8mm, 760mm Wide
Stem- Whyte Alloy, S 35mm, M/L/XL 45mm
Grips- Whyte Lock-on V Grip
Brakes Front- Tektro HD-M275, Hydraulic, 180mm Rotor
Brakes Rear- Tektro HD-M275, Hydraulic, 160mm Rotor, Internal Routing
Brake Levers- Tektro HD-M275
Pedals- Fibre Reinforced Composite Platform
